Up to 25% of your heat can be lost through the walls in an uninsulated home. Adequate, quality wall insulation is a critical component in the thermal envelope of your home. Many of New Zealand's cold, damp homes are due to little or no insulation in the ceilings, floors and walls.
- For new homes & renovations - remember it's more difficult to address wall insulation retrospectively so opt for the best wall insulation you can get. We range Mammoth polyester insulation and Pink Batts glasswool insulation.
- For existing homes address the easier to access ceiling and underfloor insulation first - then consider whether adding wall insulation is a viable option for your home.
Wall insulation is mandatory in all new homes and yet, hidden behind wall board, it doesn't always get full consideration. Your choices about insulation for your walls will have a big impact on your home's long-term comfort in summer and winter.
Our wall insulation range includes options for both 90mm and 140mm wall cavities as well as acoustic insulation products designed for internal walls (around bathrooms, bedrooms & TV areas) and mid-floor insulation.
Insulation products for 90mm wall cavity.
- Mammoth R2.0 polyester wall sections
- Mammoth R2.2 polyester wall sections
- Mammoth R2.5 polyester wall sections
- Mammoth R2.8 polyester wall sections
- Pink Batts R2.2 fibreglass wall batts
- Pink Batts R2.4 fibreglass wall batts
- Pink Batts R2.6 fibreglass wall batts
- Pink Batts R2.8 fibreglass wall batts
Insulation products for 140mm wall cavity.
- Mammoth R2.2 polyester wall blankets
- Mammoth R2.6 polyester wall blankets
- Pink Batts R3.5 fibreglass wall batts
- Pink Batts R4.0 fibreglass wall batts
- Bradford Gold R3.5 glasswool wall sections
- Bradford Gold R4.0 glasswool wall sections
NOTE: we don't offer a blow-in or foam insulation solution for walls.
Finance & Funding
New Zealand Bank Green Loan
Find out about 'Green Loans' from New Zealand's major banks of up to $50,000 at 0% interest for 5-years
4 questions & answers about this product
What R-value is needed in the walls of new homes?
The minimum thermal resistance (R-value) of new wall building systems is R1.9 other than in the South Island and the Central Plateau whether climate conditions require an R-value of 2.0
What types of retrofit wall insulation are there?
There are three main options for retrofitting wall insulation into existing homes. All these options for wall insulation retrofitting require a building consent due to the complexity of the work and the potential ramifications on the overall building envelope.
- Removing wall-board to fit insulation sections: The best, and slightly more expensive option, is to remove the wall board and fit building paper then sections of wall insulation to fully fill the wall cavity. Check our image gallery above for a handy EECA video guide to retro-fitting insulation easily, including the tip to leave a strip top and bottom to avoid the need to replace cornices or skirting boards.
- Foam wall insulation:This process involves drilling holes into the external (or sometimes internal) cladding of your home and injecting a foam - Urea Formaldehyde Foam Insulation (UFFI) into each individual wall cavity between the joists and nogs. The Building Research Association of NZ (BRANZ) has expressed concerns about shrinkage, cracking, missed sections and the installed thermal performance of foam wall insulation (refer Build Magazine article). There are also some concerns and uncertainty regarding the effect of the foam encasing electrical wiring.
- Blown fibre wall insulation: This process again requires multiple holes to be drilled into your wall to blow loose fibre insulation into each small wall cavity. The challenge with blown fibre is that it has a tendency to settle over time creating significant gaps in the wall insulation that heat readily flows through. For this reason and again the need to drill holes into each joist/nog cavity Smart Energy Solutions does not offer blown fibre wall insulation.
We do not retrofit wall insulation unless it is a major consented renovation where you are removing or replacing the wall board.
Are there risks to injected or blown-in wall insulation?
Injected insulation foams or blown-in loose insulation requires holes to be made into each individual wall cavity to inject/blow-in the insulation. A single wall may have 9 - 16 or more individual cavities.
The risks come if the hole is drilled from the outside as watertightness may be compromised. The Energywise website states "it creates a higher risk to the weathertightness of the cladding and damages the wall underlay".
Injecting from the inside creates less risk but does require some redecoration to cover the drill holes.
What alternatives are there to retrofitting wall insulation?
- Thermal curtains: Heat will flow through the weakest part of your wall system which will always be the windows if you haven't got effective thermal curtains. Make sure they are well fitted and touch the floor to limit air flow.
- Ventilation: If your issue is damp or mould then effective ventilation (either natural or mechanical) may have a greater effect than wall insulation. Read more about ventilation.
- Wall Covering: For an existing masonry/concrete block wall, you can add Mammoth wall covering to improve the situation. Mammoth wall covering is an acoustic solution with a low R-Value but for a concrete block wall it can reduce the radiant cold effect and improve the comfort of rooms. It is available in a choice of colours and is glued to the concrete wall.
1 customer reviews
Very respectful, nice employees, answered all my questions concerning insulation. Very prompt and efficient.
Wendy, Auckland
Need home insulation installed?
Fill in your details below and we will be in touch to discuss a suitable solution for your home insulation.
Hate filling in forms? Call us direct 0800 888 766
We answer 24 hours, 7 days a week so call us anytime.
New build home wall insulation.
Wall insulation is mandatory in all new homes and yet, hidden behind wall board, it doesn't always get full consideration. Your choices about insulation for your walls will have a big impact on your home's long-term comfort in summer and winter.
Some of the questions that need to be asked include:
- Should I use fibreglass or polyester insulation?
- Is the minimum building code R-value enough?
- Should I add acoustic insulation to key internal walls?
- What happens if insulation in the wall settles over time?
If you're building a new home contact us at Brightr to find out how to improve its comfort and energy efficiency. Call us on 080 888 766 or email your house plans to newbuild@brightr.co.nz
